Wood Grain Aluminum Coil

Wood grain aluminum coil can be used to decorate a variety of decorative types, from windows to arch soffits, sidings, and roof edges. Its properties are very stable, corrosion-resistant, and the surface service life is up to 30 years without decay. It can be firmly combined with a variety of building materials. The unit volume weight of aluminum trim coil is the lightest among metal materials. It is widely used in plastic panels, aluminum veneers, aluminum ceilings, roof surfaces, decorations, cans, electronic products, etc. Wanzhi Steel provides a wide range of sizes of wood grain aluminum coils, wood grain galvanized coils, wood grain styles can be specified, and paint film thickness can also be specified. At the same time, we also have striping services, which can produce wood grain aluminum trim coils with widths from 10mm to 2500mm. Welcome to inquire~

Wood Grain Steel Coil

Double-side Wood Grain Metal

Wood grain aluminum coil Specification

What is wood grain aluminum coil?

It is a lightweight, high-hardness coil with a surface treatment that simulates wood, which is realistic, three-dimensional, and has good processing adaptability. It is used to cover decorative objects (window and door frames, arch soffits, and other architectural decorations.

An aluminum trim coil is an important material in interior decoration. It was first used in suspended ceilings. Aluminum strips of different colors create different senses of space and styles.

Wood grain inspection

Wood grain rolls produced by Wanzhi

Key Features

Wood grain aluminum coil is a high-grade metal decorative material that directly produces simulated patterns on the surface of aluminum coils of a certain thickness, that is, it feels strong when touched.

The wood grain aluminum substrate adopts single-layer aluminum coil for curtain walls such as 1100H24, 1060H24, 3003H24, and 5005H24. The thickness of the aluminum coil (plate) is from 0.18-1.2mm and the width is up to 1650mm, which can meet the needs of different architectural designs. It has many advantages:

1. Appearance beauty: Through thermal transfer, roller printing, etc., the texture and color of wood are accurately copied to the surface of aluminum coils to meet the pursuit of natural wood beauty. Other colors can also be mixed, with a variety of choices.
2. Strong durability: Compared with solid wood, wood grain aluminum coils are more wear-resistant and impact-resistant, and will not crack or deform.
3. Good weather resistance: Fearless of various indoor and outdoor environments. It is resistant to ultraviolet rays, corrosion, acid, and alkali, can maintain stable performance in harsh climates, and does not easily fade or age.
4. Good fireproof performance: Aluminum alloy is a non-combustible material that can effectively prevent the spread of fire and provide higher fire safety protection for buildings
5. Sound insulation and heat insulation: It can effectively reduce the transmission of external noise, reduce the loss or absorption of indoor heat, and improve the comfort and energy-saving effect of buildings.
6. Good processing performance: It has strong plasticity and can be cut, bent, stamped, and welded, such as making wall panels, ceilings, door and window frames, decorative lines, etc.
7. Easy installation: It is a lightweight metal that is easy to carry and install, and can be installed in a variety of ways, such as snap-on, hanging, screw fixing, etc. It has a fast installation speed, which can effectively shorten the construction period, and reduce labor intensity and construction costs.
8. Low maintenance cost: You only need to rinse or wipe the stains on the surface regularly, and cleaning is very simple, without the need for painting or waxing like solid wood.

Wood-Grain

Wood-Grain-Patterns

Main Specifications

• Alloy grade: Common alloy grades include 1050, 1060, 3003, 3004, 3104, 3105, 5052, etc.
• Thickness: Generally between 0.15mm and 3mm, which can be customized according to customer needs.
• Width: Usually between 10mm and 2500mm, the specific width depends on the production equipment and customer needs.
• Coating type: Common coating types include PE (polyester), SMP (silicon modified polyester), HDP (high weather resistant polyester), PVDF (fluorocarbon), etc.
• Color: It can be customized according to customer needs. Common colors include imitation wood grain, imitation stone grain, metallic color, etc.

Application areas

Typical uses also include using this aluminum decorative roll to make eaves, J-shaped grooves, corner columns, and roof flashings. Another important use is shutter materials, you can choose one or more colors to match the decoration style of your home or the exterior wall of the building.

Applicable occasions

Commercial buildings, airports, highway stations, subways, gymnasiums, schools, hospitals, administrative buildings, tunnels, opera houses, hotels

Specific uses

Building exterior walls, outdoor curtain walls, indoor ceilings, halls, partitions, doors and windows, indoor walls, aisles, background walls, balconies, columns and beams, elevators, cabinets, stairs, etc., general bedrooms, curtain boxes, bay windows

Wood grain corrugated fence board

Indoor wall

Park decoration

Pre-purchase tips

It is worth mentioning that aluminum coils can be divided into indoor coating and outdoor coating according to the environment and economy. When purchasing aluminum trim products, it is best to choose PVDF-coated aluminum trims. PE-coated aluminum trims are similar to PVDF aluminum trims in appearance, but the price and service life are quite different. Be cautious when purchasing. The following is for your reference:

1. Indoors are generally polyester coatings, with a dry film thickness of about 16-25um and a shelf life of more than 10 years.

2. Outdoors are fluorocarbon coatings, with a dry film thickness of about 25-30um and a shelf life of more than 15 years.

In addition to wood grain, aluminum coils also have other surface treatments, such as black, blue, green, purple, red, cyan, gray, white, and other color coatings, and according to brightness, there are high gloss, ordinary gloss, matte treatment, and other processes.

Package of Aluminium Coil

Packaged Color Coated Coils

Package of wood grain aluminum coil

Wanzhi Steel Factory

We are a wood grain aluminum coil manufacturer and supplier offering good prices 1100H24, 1060H24, 3003H24, 5005H24, etc.

Besides, we use imported fully automatic high-speed painting lines, spray high-quality paint, high-quality painted aluminum strips, flat board surface, no color difference, strong coating adhesion, acid and alkali salt spray erosion resistance, no shedding, service life of more than 20 years, easy maintenance, just rinse with water to be as bright as new, can be used under large temperature changes, so it is a lucrative investment project.

If you are looking for suitable materials for your solution, Wanzhi Steel is worthy of your trust. We have guaranteed product quality and rich export experience. The factory is in Boxing County, Shandong, with a monthly output of 1,500 tons, and accepts a wide range of customized styles. Except this, Color coated aluminum coil, and other Wood Grain metals are hot selling.

Please feel free to contact us for details~
